How to unbrick Micromax AQ4502 Canvas A1 Stock Rom V1

This is a simple, easy and safe guide to unbrick Micromax AQ4502 Canvas A1 Stock Rom V1 installation with image tutorial.

Hi, This is unbrick Micromax AQ4502 Canvas A1 Stock Rom V1 by Micromax and in this post we will know how to flash stock Rom of Micromax AQ4502 Canvas A1 by easy and safest method. Micromax AQ4502 Canvas A1 has MediaTek Quad Core 1.3 GHz processor and a 4.5 inch screen with 480 x 854 Pixels resolution. It has 1GB RAM, 4GB storage, 5 MP Rear and 2 MP Front Camera. True color (16 M) and 4.4.2 Android Kitkat.

Preparation of flash or update:

1. Take a backup of your phone Click here.
2. Your phone battery should charge 80% minimum.
3. Read all steps then do it careful.
4. Make sure proper power backup of your PC.

Must Read: How to hide your apps from Android or iOS

Download ROM and Tools of Micromax AQ4502 Canvas A1:

File Name Download link
Micromax AQ4502 Canvas A1 Stock Rom V1 Kitkat Download
Micromax AQ4502 Canvas A1 SP Tool V5.1616 Download
Micromax AQ4502 Canvas A1 USB Driver Download

How to unbrick Micromax Canvas A1 Stock Rom V1:

Step 1: Install drivers on your PC and Enable USB Debugging on your Phone. Go to Settings >>> Developer options >>> USB debugging check it ( If your phone have Android 4.2 or upper version then see how to enable Developer options here is guide of this Click here). After then switch off your phone.


Step 2: Extract Stock ROM and SP Tool folder, where you want. Open the SP Tool and run Sptool.exe as Administrator.


Step 3: Click on Scatter-Loading option. SPTool ask you the location of the scatter file in your PC. You will find it in the extracted Stock ROM folder. Now go to the Rom folder and select the file “Android_scatter_emmc.txt” which is your stock Rom scatter file.


Step 4: Now Select firmware upgrade from drop-down menu then click on Download. And Connect your switch off phone with The PC via USB cable (Make sure your phone is switched off).


Step 5: SP Tool auto-detect your phone and process will start. If Sptool is not recognize/detect your phone then install vcom driver read this post it will help you click here (Driver already in phone flash drive if you don’t have these drivers then install it). After install Vcom driver reconnect your switched off phone with the PC. If you phone again not recognized by your SP Tool then try to flash via Meta mode flashing process, here is Meta-Mode flash guide click here.


Note: Don’t interrupt this process as it can potentially brick your device. Make sure no power interruption takes place.

Step 6: Now start downloading Stock Rom in your phone by flashing. After the process complete, a green ring will appear. Now disconnect your updated Smartphone.

Must Read: Use smart lock to remove password at trusted place on Android

I hope you like this Unbrick Micromax Canvas A1 Stock Rom V1 installation guide from which you will be able to easily Unbrick Micromax AQ4502 Canvas A1 Stock Rom V1 without any extra efforts. If feel any problem in this guide then please use comment box. Thanks to all.

Note: I am not responsible if you make Mistakes and Bricked Devices.
